Bundle 6C-WIEGAND GARLAND WORK GREY SEC CABLES 100M SPOOL 6C-WIEGAND-S-100

SKU
408861
Brand
MPN
6C-WIEGAND-S-100-GREY
Warranty
Standard Manufacturer's Warranty
Availability
Preorder (Contact Us)
Freight Estimate
$83.00
Buy Now And Earn 83 Reward Points!

The Garland Work 6C-7020 screened Wiegand cable is designed for low-bit-rate serial data applications and includes a screen to protect against electrical interference.

Ideally suited for short-run applications to connect motion and entry sensors (reed switches) or card readers and door strikes.

Available in 100m spools and 300m pull box.

Cores 6
Conductor AWG 24
Conductor Stranding (mm) 7/020
Material Tinned Annealed Copper Wire
Applicable Standards AS/ACIF S008, AS 1049, UL444
ROHS Compliant Yes
A-Tick Yes
Insulation Material Polypropylene
Outer Sheath Material 4V-75 PVC
Shielding Aluminium Polyester Tape Overall Screen
Colour Grey
6C-WIEGAND GARLAND WORK GREY SEC CABLES 100M SPOOL
