- Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6
- Product Segment
AC3100 ultimate AC performance : 1000+2167 Mbps
- Wi-Fi Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 600 Mbps
802.11n TurboQAM : up to 800 Mbps
802.11ac : up to 1734 Mbps
1024QAM (2.4GHz) : up to 1000 Mbps
1024QAM (5GHz) : up to2167 Mbps
- xDSL Data Rate
G.fast Upstream: 500Mbps, Downstream: 900Mbps
VDSL2 profile 35b Upstream: 100Mbps, Downstream: 300Mbps
VDSL2 profile 30a Upstream: 100Mbps, Downstream: 200Mbps
VDSL profile 17a Upstream:50Mbps, Downstream:100Mbps
VDSL profile 12a,12b Upstream:22Mbps, Downstream:68Mbps
VDSL profile 8a,8b,8c,8d Upstream:16Mbps, Downstream:50Mbps
ADSL2 Upstream: 3.3Mbps, Downstream: 24Mbps
ADSL2 Upstream: 3.5Mbps, Downstream: 12Mbps
- Features
‧DHCP server, firewall/NAT, DynDNS
‧VPN server(PPTP/Open VPN)
‧VPN client(PPTP/L2TP/Open VPN)
‧Dual WAN Fail over/Fail back
‧Quality of Service (QoS)
‧IPTV(VDSL/ADSL WAN)
‧DSL feedback mechanism
‧Save/Resotre configuration file
- Antenna
Detachable dBi antenna x 4
- LED Indicator
Power, VDSL, Internet, LAN x 2, 5 GHz Wi-Fi, 2.4 GHz Wi-Fi, USB x 1, E-WAN
- Button
WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button
- Ports
1 x RJ11 for xDSL
4 x RJ45 10/100/1000/Gigabits BaseT for LAN
1 x RJ45 10/100/1000/Gigabits BaseT for WAN
- USB Ports
USB 2.0 x 1
USB 3.0 x 1
- USB Applications
Printer Server
FTP Server
Download Master
3G/4G sharing
- Operating Frequency
2.4GHz
5GHz
- Operation Channel
13 Europe (ETSI)
- Security
WPA2-PSK, WPA-PSK
- Management
Web-based GUI configuration
Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI
Auto VPI/VCI detection
Configuration backup and restore
- VPN Support
PPTP Pass-Through
OpenVPN server
PPTP client
L2TP client
OpenVPN client
- Power Adapter
AC Input : 110 ~240 V(50~60HZ)
DC Output : 19 V/3.42 A
- Dimensions
292 x 180 x 61 ~ mm (WxDxH) (Without Bezel)
- Weight
795 g (Device Only)
- OS Support
Windows® 10
Windows® 8.1
Windows® 8
Windows® 7
Windows® XP
Mac OS X
- Package Content
VDSL/ADSL DSL-AC88U
Network cable (RJ-45)
Power adapter
Splitter
DSL Cable
Warranty card
Quick Start Guide
Support CD
