ION F18 IOT 1000VA / 1000W Double Conversion Online, 1.0 PF, Pure Sine Wave, 2U Rack/ Tower, 8 x IEC C13, 3 Year Advanced Replacement Warranty F18-IOT-1KW-RT

SKU
416369
Brand
MPN
F18-IOT-1KW-RT
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $981.00 Regular Price $1,129.00
Buy Now And Earn 981 Reward Points!

The all new ION F18 IOT Unity Rack/Tower UPS delivers online power quality and scalable battery runtimes for rack servers, voice and data networks, storage systems and other IT equipment. With an efficiency rating of >97%, the F18 UPS cuts energy costs while packing up to 3kW of power into only 2RU of rack space. The F18 UPS range also has a LCD user interface to simplify monitoring and IOT communications as standard. The F18 range is the perfect way to flexibly integrate reliable power supply and protection for high-end computing and applications exposed to potential data loss, corruption and downtime.

  • Capability to connect to cloud.
  • Grouped programmable outlets
  • Unity 1.0 power factor
  • Wide voltage input range
  • High efficiency
  • Optional additional batteries for extendable run time
  • Easy battery replacement, hot swappable
  • Automatic detect numbers of EBM
  • Power management software
  • Optional SNMP & relay cards
  • Optional Wi-Fi communication module
  • Compact design (2RU)
  • Flexible rack/tower footprint

Technical Details

Model NumberF18-IOT-1KW-RT
Capacity VA1000W/1000VA
TopologyDouble Conversion Online
Sine WavePure Sinewave
Form FactorRack / Tower
Active CoolingNo
SNMP CompatibleYes
Hard-LineNo
Hot Swappable BatteriesYes
Australian Outlets - Surge ProtectionSingle Phase
Expandable BatteriesYes
IEC 13 Count8
Australian Outlets - UPS0
IEC 19 Count0
Voltage Range200-240Vac
Voltage230Vac
Frequency Range50/60 Hz +/- 3 Hz (auto sensing)
Output Voltage230Vac
Battery Type12V 7AH (x3)
Phase CountSingle Phase
Surge ProtectionNA
InterfaceRS232 / USB / EPO
SoftwareNA
LCD AlarmAC Mode, Battery Mode, Low Battery, Fault, Overload
Audible AlarmBatt. Mode, low battery, overload, fault, etc.
Operating Temperature Range0-40 C
Noise LevelLess than 45dB
Dimensions85.5mm x 438mm x 445mm
Weight15.5kg
Warranty3 Years
The all new ION F18 IOT Unity Rack/Tower UPS delivers online power quality and scalable battery runtimes for rack servers, voice and data networks, storage systems and other IT equipment. With an efficiency rating of >97%, the F18 UPS cuts energy costs while packing up to 3kW of power into only 2RU of rack space. The F18 UPS range also has a LCD user interface to simplify monitoring and IOT communications as standard. The F18 range is the perfect way to flexibly integrate reliable power supply and protection for high-end computing and applications exposed to potential data loss, corruption and downtime.
