Datalogic GD4520 Kit 2D Mpixel Imager USB-onlyGryphon I GD4520 Kit 2D Mpixel Imager USB-only Black (Kit includes Scanner and USB Cable 90A052258) GD4520-BKK1

SKU
416621
Brand
MPN
GD4520-BKK1
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $465.00 Regular Price $535.00
Buy Now And Earn 465 Reward Points!

GD4520 Kit 2D Mpixel Imager USB-onlyGryphon I GD4520 Kit 2D Mpixel Imager USB-only Black (Kit includes Scanner and USB Cable 90A052258)

IMAGING TECHNOLOGY
The Gryphon™ 4500 series represents the premium range of hand held scanners from Datalogic for general purpose applications. Designed with people in mind, the Gryphon I GD4500 imager stands out with an elegant and trendy design, unchallenged ergonomics and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.

TOP TECHNOLOGIES FOR TODAY'S POS
Perfect for both hand held and presentation reading, the Gryphon I GD4500 imager exploits Datalogic's Motionix™ motionsensing technology which detects the natural actions of the operator to automatically switch the scanner into the desired scanning mode. This technology works with or without the use of a stand, offering more operational choices. Both the aimer and sensor can be programmed to the user's desired preferences.

Datalogic distinctive reading technology with highly visible white-illumination is easier on the human eyes and reads colored labels better. The highly visible 4-Dot aimer defines a precise reading zone and reduces accidental reads, while the aimer's center cross provides a locator for targeted scanning in a multiple bar code environment.

SIMPLE TO USE AND DEPLOY
The Gryphon I GD4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes as well as postal, stacked and composite codes like PDF417. High Density (HD) models are also available for reading smaller, condensed codes. A dedicated version with red illumination optics reads Digital Watermarking. For mobile marketing or ticketing applications, this imager also offers excellent performance when reading bar codes from mobile devices.

The enhanced optics offer improved motion tolerance and high speed imaging to read fast moving codes.
Interfaces/Ports
Host InterfaceUSB
Technical Information
Barcode Symbology Supported
    1D:
    • Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
    2D:
    • Aztec Code
    • China Han Xin Code
    • Data Matrix
    • MaxiCode
    • Micro QR Code
    • QR Code
    Postal Codes:
    • Australian Post
    • British Post
    • China Post
    • IMB
    • Japanese Post
    • KIX Post
    • Planet Code
    • Postnet
    • Royal Mail Code (RM4SCC)
    Stacked Codes:
    • EAN/JAN Composites
    • GS1 DataBar Composites
    • GS1 DataBar Expanded Stacked
    • GS1 DataBar Stacked
    • GS1 DataBar Stacked Omnidirectional
    • MacroPDF
    • MicroPDF417
    • PDF417
    • UPC A/E Composites
    Digital Watermarking:
    • Digimarc Barcodes
Connectivity TechnologyCable
Scanning Distance710 mm
Image FormatsJPEG
BMP
TIFF
Scanner RangeStandard Range
Drop SpecificationWithstands repeated drops from 1.8 m / 6.0 ft onto a concrete surface.
Image Sensor TypeImager
Cable Type IncludedUSB
Scanning Capability2D
1D
Reading Angle (Skew)65°
Reading Angle (Pitch)65°
Reading Angle (Roll)360°
Motion Tolerance889 mm/s
Maximum Ambient Light100000 lux
Minimum Print Contrast15%
Minimum Element Resolution (Code 39)0.13 mm
Maximum Element Resolution (Code 39)0.25 mm
Minimum Element Resolution (DataMatrix)0.25 mm
Maximum Element Resolution (DataMatrix)0.38 mm
Minimum Element Resolution (PDF417)0.25 mm
Miscellaneous
Application/UsageIndustrial
Retail
Healthcare
Transportation
Country of OriginVietnam
Environmentally FriendlyYes
Physical Characteristics
Weight (Approximate)161 g
Form FactorHandheld
Length220 mm
Height95 mm
Width110 mm
Product ColorBlack
General Information
Product TypeBarcode Scanner Kit
Manufacturer Part NumberGD4520-BKK1
Manufacturer Website Addresshttp://www.datalogic.com
Packaged Quantity2
ManufacturerDatalogic S.p.A
Product ModelGD4520
Product NameGryphon GD4520 Handheld Barcode Scanner Kit
Product LineGryphon
Product SeriesGD4500
Brand NameDatalogic
