GIGABYTE UD850GM PG5 POWER SUPPLY, 850W, MODULAR, 10YR WTY GP-UD850GM-PG5-V2

SKU
398164
Brand
Gigabyte
Manufacturer Link
MPN
GP-UD850GM-PG5-V2
Manufacturer Product Link
Warranty
Standard Manufacturer's Warranty
Availability
Preorder (Contact Us)
Freight Estimate
$173.00
Buy Now And Earn 173 Reward Points!
Add to Compare
GIGABYTE UD850GM PG5 POWER SUPPLY, 850W, MODULAR, 10YR WTY
  • Model
    GP-UD850GM PG5
  • Type
    Intel Form Factor ATX 12V
  • PFC
    Active PFC (>0.9 typical)
  • Input Voltage
    100-240 Vac (full range)
  • Input Current
    12-6A
  • Input Frequency
    60-50 Hz
  • Output Capacity
    850W
  • Dimension
    150 x 140 x 86 mm
  • Fan Type
    120mm Hydraulic Bearing(HYB)fan
  • 80 PLUS
    Gold
  • Efficiency
    90% at typical load
  • MTBF
    >100,000 hours
  • Protection
    OVP/OPP/SCP/UVP/OCP/OTP
  • Power Good Signal
    100-150ms
  • Hold Up Time
    >16ms
  • Cable Type
    Flat, All black
  • Connectors
    ATX/MB 20+4 Pin x 1 : 610mm*1
    CPU/EPS 4+4 Pin x 2 : 600mm+200mm*1
    PCI-e 12+4 Pin x 1: 700mm*1
    PCI-e 6+2 Pin x 4 : 600mm+150mm*2
    SATA x 8 :
    600mm+150mm+150mm+150mm*2
    4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1
