LAN-8723 GARLAND WORK 2PR 7025 LNDI SCR GREY SEC CABLE 100M DRUM MCP2ISGY100W

SKU
409398
Brand
MPN
LAN-7025-S-100-GREY
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
$100.00
Buy Now And Earn 100 Reward Points!

The Garland Work MCP range of cables is polypropylene insulated and PVC sheathed. Overall screened versions carry an "S" suffix and individual and overall screened versions carry an "ISCS" suffix. This range of cables is designed for low-bit-rate data transmission of up to 10 MB in an indoor or in-building environment. Available in 100m spool and 300m Pull Box. Often referred to as LAN-8723 or sometimes "Belden" in the security market it is used in the following applications: - Credentials - Access applications - Challenger DGP - OSDP - WAP - door strikes - motion sensors - IR sensors - keypads - alarm modules

No Pairs 2 Twisted Pairs
Conductor AWG 24
Conductor Stranding (mm) 7/020
Material Tinned Annealed Copper Wire
Applicable Standards AS/ACIF S008, AS 1049, UL444
ROHS Compliant Yes
A-Tick Yes
Insulation Material Polypropylene
Outer Sheath Material 4V-75 PVC
Shielding Aluminium Polyester Tape Overall Screen
Colour Grey
LAN-8723 GARLAND WORK 2PR 7025 LNDI SCR GREY SEC CABLE 100M DRUM
