LINKSYS MGBLX1 Gigabit Ethernet LX Mini-GBIC SFP Transceiver MGBLX1

Name: LINKSYS MGBLX1 Gigabit Ethernet LX Mini-GBIC SFP Transceiver MGBLX1
Brand: Linksys
SKU: 54904
Price: 311 AUD
Availability: InStock

SKU

54904

Brand

Linksys

Manufacturer Link

MPN

MGBLX1

Warranty

1 Year Manufacturer's return to base

Availability

Preorder (Contact Us)

Freight Estimate

$311.00

Buy Now And Earn 311 Reward Points!

Cisco MFE and MGE Small Form-Factor Pluggable (SFP) or mini Gigabit Interface Converter (mini-GBIC) transceivers (Table 1) are easy-to-install modules that provide a simple way to add fiber connectivity or to add an extra Gigabit Ethernet port to your Cisco Small Business or Cisco Small Business Pro Series switches. The transceivers are available for single-mode or multimode fiber-optic cabling and can support distances from 100 meters up to 40 kilometers.

The Cisco MFE and MGE transceivers provide fast and reliable connectivity between switches that are located on different floors, in separate buildings, or on a small campus network needing connectivity between sites. These transceivers can support both Fast and Gigabit Ethernet applications.

Table 1. MFE and MGE SFP Transceiver Modules

	Description
MFE Transceivers
MFEBX1	100BASE-BX-20U SFP transceiver for single-mode fiber, 1310 nm wavelength, support up to 20 km
MFEFX1	100BASE-FX SFP transceiver, for multimode fiber, 1310 nm wavelength, support up to 2 km
MFELX1	100BASE-LX SFP transceiver, for single-mode fiber, 1310 nm wavelength, support up to 10 km
MGE Transceivers
MGBBX1	1000BASE-BX-20U SFP transceiver, for single-mode fiber, 1310 nm wavelength, support up to 20 km
MGBLH1	1000BASE-LH SFP transceiver, for single-mode fiber, 1310 nm wavelength, support up to 40 km
MGBLX1	1000BASE-LX SFP transceiver, for single-mode fiber, 1310 nm wavelength, support up to 10 km
MGBSX1	1000BASE-SX SFP transceiver, for multimode fiber, 850 nm wavelength, support up to 550 m
MGBT1	1000BASE-T SFP transceiver for category 5 copper wire, support up to 100 m

Features

Built-in spring latch for easy module removal

Hot swappable

Low insertion-loss duplex LC receptacle

Low electromagnetic interference (FCC Part 15, Class B) for clear communications

Meets FDA and International Electrotechnical Commission (IEC) eye safety standards

Cisco Limited Warranty

The Cisco Small Business transceivers come with a 5-year limited hardware warranty with return to factory replacement. In addition, Cisco offers software updates for bug fixes at no charge for the life of the warranty and one year of telephone technical assistance from the Small Business Support Center. For more information visit, http://www.cisco.com/en/US/docs/general/warranty/5year_SmallBusiness.html.

PI Date	Jun 2010
Brand Name	Cisco
Manufacturer Web Site	http://www.cisco.com
Form Factor	SFP
Product Line	Not defined
Product Model	Not defined
Product Type	Transceiver
Cable Type	Single Mode Fiber (SMF)
Connector	1x LC
Core Size	Not availablemicrons
Interface	1000 Base-LX(ST)
Maximum Transmission Distance	10000meter
Wavelength	1310nm
Depth (mm)	55.7
Height (mm)	8.5
Width (mm)	13.4
Weight (Grams)	0.018 kg
Other Features	Adds fiber-optic connectivity to Cisco Small Business and Cisco Small Business Pro Series switches. High-performance link for connecting networks within a building or small campus area. Easy removal with an integrated spring latch. Hot swappable to maintain network availability.
