DESCRIPTION

Technical Spec.

GPU Engine Specs:
CUDA Cores 2304
Boost Clock (MHz) 1470
Base Clock(MHz) 1042
Thermal and Power Spec:
Minimum System Power Requirement (W) 450
Supplementary Power Connectors NA
Memory Specs:
Memory Clock 14Gbps
Standard Memory Config 6GB
Memory Interface GDDR6
Memory Interface Width 96-bit
Memory Bandwidth (GB/sec) 168
Feature Support:
Real-Time Ray Tracing Yes
Ray Tracing Cores 2nd Generation
Tensor Cores 3rd Generation
NVIDIA Architecture Ampere
Microsoft DirectX 12 Ultimate
NVIDIA DLSS Yes
PCI Express Gen 4 Yes
NVIDIA GeForce Experience Yes
NVIDIA Ansel Yes
NVIDIA FreeStyle Yes
Bus Support PCI-E 4.0
NVIDIA ShadowPlay Yes
OS Certification Windows 10, Linux, FreeBSDx86
NVIDIA Highlights Yes
NVIDIA G-SYNC™-Ready Yes
Game Ready Drivers Yes
NVIDIA Studio Drivers Yes
NVIDIA GPU Boost™ Yes
Vulkan API Yes
OpenGL 4.6
HDMI 2.1 Yes
DisplayPort 1.4a Yes
NVIDIA Encoder 7th Generation
NVIDIA Decoder 5th Generation
Accessories:
Installation Guide Yes
Power Guide Yes
Graphics Card Dimensions:
Length 222mm
Height 120mm
Width 2-slot
Display Support:
Multi Monitor Yes
Maxmium Digital Resolution 7680x4320
HDCP 2.3
Standard Display Connectors HDMI 2.1, DisplayPort 1.4a, DVI-D
