Startech 4 Port High Speed Hdmi Video Splitter W/ Audio St124hdmi2
| General Information | |
|---|---|
| Brand Name: | StarTech.com |
| Manufacturer Part Number: | ST124HDMI2 |
| Manufacturer Website Address: | http://www.startech.com |
| Manufacturer: | StarTech.com |
| Marketing Information: | Split an HDMI® audio and video signal to four displays simultaneously. The ST124HDMI2 4 Port High Speed HDMI® Video Splitter with Audio lets you share a single HDMI source with up to 4 HDMI or DVI-D enabled displays/receivers, without sacrificing image or sound quality. Supporting true HD video resolutions up to 1080p, this HDMI splitter allows you to situate your HDMI-capable displays up to 15ft (5m) away from the splitter. This versatile HDMI splitter features 3.5mm audio input and output connections giving you the option of sending your accompanying audio signal through the HDMI cable or through a separate 3.5mm stereo audio channel. A perfect addition to virtually any application requiring the high quality video delivered by HDMI devices, the ST124HDMI2 video splitter is easy to install and provides flawless, distortion-free digital video. Backed by a StarTech.com 2-year warranty and free lifetime technical support. |
| Packaged Quantity: | 1 |
| Product Name: | 4-Port HDMI Splitter and Signal Amplifier |
| Product Type: | Audio/Video Switchbox |
| Interfaces/Ports | |
|---|---|
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| HDMI In: | Yes |
| HDMI Out: | Yes |
| Number of HDMI Inputs: | 1 |
| Number of HDMI Outputs: | 4 |
| Media & Performance | |
|---|---|
| Maximum Operating Distance: | 9.14 m |
| Miscellaneous | |
|---|---|
| Green Compliant: | Yes |
| Physical Characteristics | |
|---|---|
| Depth: | 221 mm |
| Height: | 43.9 mm |
| Weight (Approximate): | 1.07 kg |
| Width: | 134.6 mm |
| Technical Information | |
|---|---|
| Device Supported: | Computer |
| Display | |
| Number of Displays Supported: | 4 |
| Number of Input Devices Supported: | 1 |
| Video | |
|---|---|
| Graphics Modes: | WUXGA |
| Maximum Video Resolution: | 1920 x 1200 |
| Scan Format: | 1080p |
| Connector(s) | |
| Connector A | 3.5 mm Mini-Jack (3 Position) Female |
| HDMI (19 pin) Female | |
| Connector B | 3.5 mm Mini-Jack (3 Position) Female |
| HDMI (19 pin) Female | |
| Environmental | |
| Humidity | 0%~80% |
| Operating Temperature | 0?C to 40?C (32?F to 104?F) |
| Storage Temperature | -20?C to 60?C (-4?F to 140?F) |
| Hardware | |
| Audio | Yes |
| Cabling | HDMI |
| Industry Standards | High Speed HDMI?, HDCP, EDID |
| Ports | 4 |
| Indicators | |
| LED Indicators | Green Port signal indicator |
| Power (Green) / Input Signal (Blue) | |
| Packaging Information | |
| Shipping (Package) Weight | 1.6 kg [3.5 lb] |
| Performance | |
| Maximum Cable Length | 15.2 m [50 ft] |
| Maximum Digital Resolutions | HDTV 1080p / PC 1920x1200 |
| Supported Resolutions | 1080p (1920 x 1080) / VGA (640 x 480) / SXGA (1280 x 1024) / UXGA (1600 x 1200) / WUXGA (1920 x 1200) |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Steel |
| Product Height | 44 mm [1.7 in] |
| Product Length | 220 mm [8.7 in] |
| Product Weight | 1074 g [37.9 oz] |
| Product Width | 135 mm [5.3 in] |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.8A |
| Input Voltage | 110V-240V AC |
| Output Current | 1.5A |
| Output Voltage | 12 DC |
| Plug Type | M |
| Power Consumption (In Watts) | 18 |
| Power Source | AC Adapter Included |
| What's in the Box | |
| Included in Package | HDMI splitter |
| instruction manual | |
| mounting hardware and screw kit | |
| universal power adapter (NA / EU / UK / AU) | |
The ST124HDMI2 4 Port High Speed HDMI® Video Splitter with Audio lets you share a single HDMI source with up to 4 HDMI or DVI-D enabled displays/receivers, without sacrificing image or sound quality. Mounting brackets are included for a tidy, professional installation.
Supporting true HD video resolutions up to 1080p, this HDMI splitter allows you to situate your HDMI-capable displays up to 15ft (5m) away from the splitter. This versatile HDMI splitter features 3.5mm audio input and output connections giving you the option of sending your accompanying audio signal through the HDMI cable or through a separate 3.5mm stereo audio channel.
A perfect addition to virtually any application requiring the high quality video delivered by HDMI devices, the ST124HDMI2 video splitter is easy to install and provides flawless, distortion-free digital video.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
