Startech Usb 3.0 To 2.5 Sata Iii Hard Drive Adapter Cable W/ Uasp Sata To Usb 3.0 Converter For

SKU
191548
Brand
MPN
USB3S2SAT3CB
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $20.00 Regular Price $23.00
Buy Now And Earn 20 Reward Points!

QUICK OVERVIEW

SSD/ HDD - 2.5in SATA Hard Drive to Superspee USB3S2SAT3CB

Connect a 2.5in SATA hard drive to your computer using a portable cable with UASP Support. The USB3S2SAT3CB USB 3.0 to SATA adapter cable lets you connect a 2.5

Product Name StarTech USB3S2SAT3CB USB3.0 to 2.5 SATA III Hard Drive Adapter Cable W Uasp
Product Type Data Transfer/Power Cable
Cable Type SATA/USB
Packaged Quantity 1
Cable Length 4.60"
Connector on First End 1 x 15-pin Male SATA 3.0 SATA
1 x 7-pin Male Power
Connector on Second End 1 x 9-pin Type A Male USB 3.0 USB
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Device Supported Notebook
Ultrabook
Storage Drive
Hard Drive
Certifications & Standards
FCC
CE
Conductor Copper
Material Steel - Enclosure
Limited Warranty 2 Year

Hardware
Number of Drives1
Packaging Information
Shipping (Package) Weight61 g [2.2 oz]
Performance
4Kn SupportYes
General SpecificationsMax power of the attached drive is 900 mA
Max Drive CapacityCurrently tested with up to 2TB 5900 RPM hard drives
Hardware
InterfaceUSB 3.0
Fan(s)No
Drive Size2.5in
Compatible Drive TypesSATA
Chipset IDASMedia - ASM1153E
Bus TypeUSB 3.0
Environmental
Storage Temperature-10?C to 70?C (14?F to 158?F)
Operating Temperature0?C to 60?C (32?F to 140?F)
Humidity40%-85%RH
Connector(s)
Host ConnectorsUSB Type-A (9 pin) USB 3.0 Male
Drive ConnectorsSATA Power (15 pin)
SATA Data & Power Combo (7+15 pin) Receptacle
Performance
TRIM SupportNo
Type and RateSATA III (6 Gbps)
USB 3.0 - 5 Gbit/s
UASP SupportYes
Physical Characteristics
Product Height9 mm [0.4 in]
Product Length500 mm [19.7 in]
Product Weight41 g [1.4 oz]
Product Width49 mm [1.9 in]
Power
Power SourceUSB-Powered
Software
OS CompatibilityOS independent; No software or drivers required
Special Notes / Requirements
NoteCable will work only with 2.5" SATA drives
3.5"/5.25" drives are not supported
What's in the Box
Included in PackageInstruction Manual
USB 3.0 to SATA 2.5" HDD Adapter Cable

The USB3S2SAT3CB USB 3.0 to SATA adapter cable lets you connect a 2.5" SATA hard drive or solid state drive to your computer through an available USB port -- the easiest way to upgrade the hard drive in your laptop by adding an external SSD via USB 3.0.

The cable supports UASP, allowing for transfer speeds up to 70% faster than conventional USB 3.0, which enables you to utilize the full potential of your SATA III SSD/HDD, when paired with a UASP-enabled host controller. See our UASP testing results below for further details.

This portable adapter features a lightweight design with no external power required, for easy storage in a laptop bag or carrying case. Plus, the cable-style adapter makes it easy to swap between hard drives without having to install your drives into an enclosure. Perfect for easy drive access for data migration, drive cloning and data backup applications.

The USB3S2SAT3CB is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Connection Diagram



Improved Performance with UASP

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

UASP Speed Diagram

At the same peak in testing, UASP also shows an 80% reduction in required processor resources.

UASP Speed Diagram

Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.
