Startech Usb To Rs232 Db9/ Db25 Serial Adapter Cable - M/ M Icusb232db25
The ICUSB232DB25 USB to RS232 DB9/DB25 Serial Adapter Cable (M/M) lets you
connect 9-pin (DB9) or 25-pin (DB25) RS232 serial devices to your laptop or
desktop computer through a USB port, as though the computer offered an onboard
serial port. The integrated 3-foot (0.9 meter) cable allows it to be connected
directly from the serial device to the computer without requiring additional
cables.
A cost-effective solution that bridges the compatibility gap between modern
computers and legacy serial peripherals, this high quality USB/RS232 Serial
Adapter cable ships with a DB-9 to DB-25 adapter for connection to varied serial
equipment.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Name USB to RS232 DB9/DB25 Serial Adapter Cable - M/M
Product Type Data Transfer Cable
Cable Type Serial
Color Gray
Cable Length 3 ft
Connector on First End 1 x 9-pin DB-9 Male RS-232 Serial
Connector on Second End 1 x Type A Male USB 2.0 USB
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Certifications & Standards
FCC
CE
Conductor Copper
Additional Information Operating System(s):
Windows 8 / 7 / Vista / XP (32/64-bit)
Windows XP Embedded
Windows POS Ready 2009
Windows Embedded System 2009
Windows CE 4.2/5.2
Windows Mobile 5/6
Windows PocketPC 2000 / 2003
Windows Server 2008 R2
Windows Server 2003 (32/64-bit)
Mac OS v.10.1 and up (Tested up to v.10.8)
Linux
| Connector(s) | |
| Connector Type(s) | USB Type-A (4 pin) USB 2.0 Male |
| External Ports | DB-25 (25 pin, D-Sub) Male |
| DB-9 (9 pin, D-Sub) Male | |
| Environmental | |
| Humidity | 5~85% RH |
| Operating Temperature | 0?C to 70?C (32?F to 158?F) |
| Storage Temperature | -40?C to 85?C (-40?F to 185?F) |
| Hardware | |
| Bus Type | USB 2.0 |
| Chipset ID | Prolific - PL2303 |
| Interface | Serial |
| Port Style | Cable Adapters |
| Ports | 1 |
| Packaging Information | |
| Shipping (Package) Weight | 90 g [3.2 oz] |
| Performance | |
| Data Bits | 4, 5, 6, 7, 8 |
| FIFO | 512 Bytes |
| Flow Control | None, Xon/ Xoff, Hardware |
| Max Baud Rate | 230.4 Kbps |
| Parity | None, Even, Odd, Mark, Space |
| Serial Protocol | RS-232 |
| Stop Bits | 1, 1.5, 2 |
| Physical Characteristics | |
| Cable Length | 0.9 m [3 ft] |
| Color | Gray |
| Enclosure Type | Plastic |
| Product Length | 0.9 m [3 ft] |
| Product Weight | 70 g [2.5 oz] |
| Software | |
| Microsoft WHQL Certified | Yes |
| OS Compatibility | Windows? PocketPC 2003 / 2000, Windows Mobile 5/6, CE 4.2/5.2, Embedded System 2009, XP Embedded, POS Ready 2009, 98SE, 2000, ME, XP, Vista, 7, 8, 8.1, 10 Windows Server? 2003, 2008 R2, 2012, 2016 Mac OS X? 10.6 to 10.13 Linux 2.4.x to 4.11.x LTS Versions only |
| What's in the Box | |
| Included in Package | 3ft USB to RS232 Cable |
| DB9 to DB25 Serial Adapter | |
| Driver CD | |
| Manual | |
The ICUSB232DB25 USB to RS232 DB9/DB25 Serial Adapter Cable (M/M) lets you connect 9-pin (DB9) or 25-pin (DB25) RS232 serial devices to your laptop or desktop computer through a USB port, as though the computer offered an onboard serial port. The integrated 3-foot (0.9 meter) cable allows it to be connected directly from the serial device to the computer without requiring additional cables.
A cost-effective solution that bridges the compatibility gap between modern computers and legacy serial peripherals, this high quality USB/RS232 Serial Adapter cable ships with a DB-9 to DB-25 adapter for connection to varied serial equipment.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
