Details:

Superfast Wi-Fi – Up to 1.6Gbps

The Archer VR600 unlocks the full potential of your internet connection by providing combined dual band Wi-Fi speeds of up to 1.6Gbps, including 300Mbps on the 2.4GHz band and 1300Mbps on the 5GHz band, eliminating lag and buffering from your online experience.

Two dedicated Wi-Fi networks support more devices and reduce wireless interference to create stable connections.

• 5GHz 1300Mbps
• 2.4GHz 300Mbps

Superfast VDSL Broadband

The latest VDSL2 technology allows the Archer VR600 to deliver impressive VDSL broadband speeds of up to 100Mbps, which is almost five times faster than ADSL2+. The Archer VR600 serves as a DSL modem and wireless router, combining two devices in one. The integrated DSL port supports all standard DSL connections, including VDSL2, ADSL2+, ADSL2, and ADSL.

Versatile Connectivity

With multiple inputs, the Archer VR600 provides you with a variety of options when connecting to the Internet. As a backup, the EWAN port allows the Archer VR600 to accept connections from cable and fiber modems via Ethernet cable. Additionally, both of the two USB ports support 3G/4G dongle connections.

• EWAN Connection
• 3G/4G Dongle Connection

Superior Range and Stability

Threehigh-performance external antennas help the Archer VR600 create an expansive home network. Advanced Beamforming technology* automatically locates wireless devices and forms targeted, highly efficient wireless connections.

Blazing Fast Wired Performance

To help your wired devices achieve peak performance, the router's four Gigabit Ethernet ports operate 10x faster than standard Ethernet. Connecting an external drive to one of the USB 2.0 ports allows you to share files, photos, music, and video with any device on the network.

Impressive Aesthetics

The glossy black body of the Archer VR600 makes it a stylish addition to the decor of any room in your home. The silver accents also provide an aura of elegance, making your router easy to display, whether it is simply placed on a table or mounted on the wall. For added convenience, you can easily disable the LED indicators to prevent distractions at night.

Easy Setup and Use

Set up the Archer VR600 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and media sharing.

Specifications:

HARDWARE FEATURES

• Interface:
  • 4 10/100/1000Mbps RJ45 LAN Ports
  • 1 RJ11 Port
  • 2 USB 2.0 Ports
• Button:
  • WPS Button, LED Button, Wireless On/Off Buttons(2.4GHz & 5GHz),
  • Power On/Off Button
• External Power Supply: 12V/2A
• IEEE Standards: IEEE 802.3, IEEE 802.3u, 802.3ab
• VDSL2 Standards:
  • ITU-T G.993.2, Up to 17a profile (POTS)
  • ITU-T G.993.5 (G.vector)
  • ITU-T G.998.4 (G.INP)
• ADSL Standards:
  • Full-rate ANSI T1.413 Issue 2,
  • ITU-T G.992.1(G.DMT),
  • ITU-T G.992.2(G.Lite),
  • ITU-T G.994.1 (G.hs),
  • ITU-T G.995.1
• ADSL2 Standards:
  • ITU-T G.992.3 (G.DMT.bis),
  • ITU-T G.992.4 (G.lite.bis)
• ADSL2+ Standards: ITU-T G.992.5
• Dimensions (W x D x H): 216 x 164 x 36.8mm
• Antenna Type: 3 External detachable dual band antennas

WIRELESS FEATURES

Wireless Statistics

• Wireless Standards:
  • IEEE 802.11a/n/ac 5GHz,
  • IEEE 802.11b/g/n 2.4GHz
• Frequency: 2.4GHz and 5GHz (Supports DFS)
• Signal Rate: 1300Mbps at 5GHz, 300Mbps at 2.4GHz
• Transmit Power:
  • 2.4GHz <20dBm(EIRP)
  • 5GHz <23dBm(EIRP)
• Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM,
• Wireless Security:
  • 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
  • encryptions, Wireless MAC Filtering

SOFTWARE FEATURES

• Quality of Service: ATM QoS, Bandwidth Control
• Security:
  • NAT Firewall, Access Control,
  • IP and MAC Address Binding
• Operating Modes: VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router
• Management:
  • Web Based Configuration (HTTP), Remote management,
  • command Line Interface, SSL for TR-069, SNMP v1/2c,
  • Web Based Firmware Upgrade, Diagnostic Tools
• DHCP:
  • Server, Client, DHCP Client List, Address Reservation,
  • DHCP Relay
• Port Forwarding: Virtual Server, Port Triggering, DMZ, ALG, UPnP
• Dynamic DNS: DynDns, NO-IP
• VPN Pass-Through: PPTP, L2TP, IPSec Passthrough
• Protocols: Supports IPv4 and IPv6
• ATM/PPP Protocols:
  • ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
  • PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MERIPoE (RFC 1483
  • Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
• Advanced Functions:
  • Parental Control, Network Address Translation(NAT),
  • Port Mapping(Grouping), Static Routing, RIP
  • v1/v2(optional), DNS Relay,
  • DDNS, IGMP V1/V2/V3
• USB Sharing:
  • Support Samba(Storage)/FTP Server/Media Server/Printer
  • Server, 3G/4G Modem
• Guest Network: 2.4GHz Guest Network, 5GHz Guest Network
• IPSec VPN: Supports up to 10 IPSec VPN tunnels
• Beamforming: 5GHz Band
• APP: Tether App

OTHERS

• Certification: CE, RoHS
• Package Contents:
  • AC1600 Wireless Gigabit VDSL/ADSL Modem Router
  • Archer VR600
  • External Splitter
  • RJ11 DSL Cable
  • RJ45 Ethernet Cable
  • Power Adapter
  • Quick Installation Guide
• System Requirements:
  • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or
  • Windows 7, 8, 8.1, MAC OS, NetWare, UNIX or Linux
  • Internet Explorer 11, Firefox 12.0, Chrome 20.0,
  • Safari 4.0, or other Java-enabled browser
  • Cable or DSL Modem Subscription with an Internet
  • Service Provider (for Internet access)
• Environment:
  • Operating Temperature: 0?~40? (32? ~104?)
  • Storage Temperature: -40?~70? (-40? ~158?)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
