Interface
|
Fixed WAN Port |
1x RJ-11 for VDSL2 35b or ADSL2/2+ |
LAN/WAN Switchable Port |
1x 10/100/1000Base-T, RJ-45 (P4) |
Fixed LAN Port |
3x 10/100/1000Base-T, RJ-45 |
USB Port |
2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer |
WiFi Antenna |
2x External Dipole, Gain: 4 dBi for 5GHz, 2 dBi for 2.4GHz, (ac model) 2x External Dipole, Gain: 2.5 dBi for 5GHz, 2.7 dBi for 2.4GHz (ax model) |
2.4G WLAN |
802.11n 2x2 MIMO, Up to 400Mbps Link Rate (ac model) 802.11ax 2x2 MIMO, up to 574Mbps Link Rate (ax model) |
5G WLAN |
802.11ac Wave 2 2x2 MU-MIMO, Up to 867Mbps Link Rate (ac model) 802.11ax 2x2 MU-MIMO, up to 2402Mbps Link Rate (ax model) |
FXS RJ-11 |
2 (V model) |
Performance
|
Max. Throughput on VDSL |
300 Mbps |
NAT Throughput |
600 Mbps |
NAT Throughput w/ Hardware Acceleration |
940 Mbps |
IPsec VPN Performance |
150 Mbps (AES 256 bits) |
SSL VPN Performance |
100 Mbps |
Max. Number of NAT Sessions |
50,000 |
Max. Concurrent VPN Tunnels |
2 |
DSL
|
VDSL Standards |
ITU-T G.993.2 Annex A/B/M/Q (up to Profile 35b but excluding 30a) T1.424 ITU-T G.993.5 (Vectoring) |
VDSL2 Profile |
8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a, 35b (not G.fast) |
ADSL Standards |
ITU-T G.992.1 (G.dmt), ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.5 (ADSL2+) (G.adslplus), T1.413 Issue 2 |
Other Standards |
ITU-T G.994.1 (G.hs), ITU-T G.997.1 (G.ploam), ITU-T G.998.4 (Retransmission) |
Band Plan |
998, 997 |
Internet Connection
|
IPv4 |
PPPoE, PPPoA, DHCP, Static IP, MPoA, PPTP/L2TP |
IPv6 |
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
Multi-VLAN/PVC |
|
3G/4G/LTE WAN with USB modem |
|
WAN Failover |
|
Connection Detection |
ARP, Strict ARP, Ping |
WAN Data Budget |
|
Dynamic DNS |
|
DrayDDNS |
|
LAN Management
|
VLAN |
802.1q Tag-based, Port-based |
Max. Number of VLAN |
8 |
Number of LAN Subnet |
4 |
DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
Wired 802.1x Authentication |
|
Port Mirroring |
|
Local DNS Server |
|
Conditional DNS Forwarding |
|
Hotspot Web Portal |
|
Hotspot Authentication |
Click-Through, Social Login, SMS PIN, Mail PIN, RADIUS, External Portal Server |
Networking
|
Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2 |
Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
DNS Security (DNSSEC) |
|
IGMP |
IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
SMB File Sharing |
(Requires external storage) |
VPN
|
LAN-to-LAN |
|
Teleworker-to-LAN |
|
Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN |
User Authentication |
Local, RADIUS, mOTP |
IKE Authentication |
Pre-Shared Key, X.509 |
IPsec Authentication |
SHA-1, SHA-256, MD5 |
Encryption |
MPPE, DES, 3DES, AES128, AES192, AES256 |
Single-Armed VPN |
|
NAT-Traversal (NAT-T) |
|
DrayTek VPN Matcher |
|
Firewall & Content Filtering
|
NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
VPN Pass-Through |
PPTP, L2TP, IPsec |
IP-based Firewall Policy |
|
Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense |
|
Spoofing Defense |
|
Bandwidth Management
|
IP-based Bandwidth Limit |
|
IP-based Session Limit |
|
QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
VoIP Prioritization |
|
APP QoS |
|
Wireless LAN (ac/ax model)
|
WiFi 6 |
(ax model) |
Number of SSID |
4 per radio |
Security Mode |
OWE, WEP, WPA, WPA2, Mixed(WPA+WPA2), WPA3 |
Authentication |
Pre-Shared Key, 802.1X |
OFDMA |
(ax model) |
WPS |
PIN, PBC |
WDS |
Repeater (5GHz only) |
Access Control |
Access List, Client Isolation, Hide SSID, WLAN Scheduling |
AirTime Fairness |
|
Band Steering |
|
MU-MIMO |
(5GHz Only) |
WMM |
|
VoIP Gateway (V model)
|
Protocol |
SIP, RTP/RTCP, ZRTP |
SIP Registrars |
6 |
Dial Plan |
Phone Book, Digit Map, Call Barring, Regional |
Call Features |
Call Waiting, Call Transfer, Scheduled DND, Hotline |
Voice Codec |
G.711 A/u law, G.726, G.729 A/B |
Caller ID |
FSK_ETSI, FSK_BELLCORE, DTMF |
Management
|
Local Service |
HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
Config File Export & Import |
|
Config File Compatibility |
Vigor2760 Series, Vigor2762 Series, Vigor2763 Series, Vigor2765 Series, Vigor2766 Series |
Firmware Upgrade |
TFTP, HTTP, TR-069 |
2-Level Administration Privilege |
|
Access Control |
Access List, Brute Force Protection |
Notification Alert |
SMS, E-mail |
Netflow |
(v5, v9, IPFIX) |
SNMP |
v1, v2c, v3 |
Syslog |
|
Managed by VigorACS |
|
Central AP Management |
2 VigorAP |
Mesh Network |
7 VigorAP (ac model) |
Physical
|
Power Supply |
DC 12V @ 1.5A-2A |
Max. Power Consumption |
21.6 watts (Vac model) |
Dimension |
207mm x 131mm x 42mm 194mm x 155mm x 50mm (ax model) |
Weight |
500g (ac model) |
Operating Temperature |
0 to 45°C |
Storage Temperature |
-25 to 70°C |
Operating Humidity (non-condensing) |
10 to 90% |
Certificate |
|
