Interface
|
Fixed WAN Port |
1x GbE RJ-45 |
WAN/LAN Switchable Port |
1x GbE RJ-45 |
Fixed LAN Port |
5x GbE RJ-45 |
USB Port |
2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer |
RJ-11 Port for Voice |
2x FXS (V model) |
Wireless Antenna |
2x External Dipole Gain: 3 dBi for 5GHz, 2.5 dBi for 2.4GHz (ac/ax model) |
2.4G WLAN |
802.11n 2x2 MIMO, up to 400Mbps Link Rate (ac model) 802.11ax 2x2 MIMO, up to 574Mbps Link Rate (ax model) |
5G WLAN |
802.11ac Wave 2 2x2 MU-MIMO, up to 867Mbps Link Rate (ac model) 802.11ax 2x2 MU-MIMO, up to 2402Mbps Link Rate (ax model) |
Performance
|
NAT Throughput |
800 Mbps |
NAT Throughput w/ Hardware Acceleration |
940 Mbps (Single WAN) 1.8 Gbps (Dual WAN) |
IPsec VPN Performance |
290 Mbps (AES 256 bits) |
SSL VPN Performance |
120 Mbps |
Max. Number of NAT Sessions |
60,000 |
Max. Concurrent VPN Tunnels |
50 |
Max. Concurrent OpenVPN + SSL VPN |
25 |
Internet Connection
|
IPv4 |
PPPoE, DHCP, Static IP, PPTP/L2TP |
IPv6 |
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
802.1p/q Multi-VLAN Tagging |
|
Multi-VLAN/PVC |
|
Wireless WAN |
2 (ac model) |
3G/4G/LTE WAN with USB modem |
|
Load Balancing |
IP-based, Session-based |
WAN Active on Demand |
Link Failure, Traffic Threshold |
Connection Detection |
ARP, Ping |
WAN Data Budget |
|
Dynamic DNS |
|
DrayDDNS |
|
LAN Management
|
VLAN |
802.1q Tag-based, Port-based |
Max. Number of VLAN |
16 |
Number of LAN Subnet |
8 |
DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
LAN IP Alias |
|
Wired 802.1x Authentication |
|
Port Mirroring |
|
Local DNS Server |
|
Conditional DNS Forwarding |
|
Hotspot Web Portal |
|
Hotspot Authentication |
Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
Networking
|
Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2, BGP |
Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
High Availability |
|
DNS Security (DNSSEC) |
|
IGMP |
IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
Local RADIUS server |
|
SMB File Sharing |
(Requires external storage) |
VPN
|
LAN-to-LAN |
|
Teleworker-to-LAN |
|
Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN |
User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
IKE Authentication |
Pre-Shared Key, X.509 |
IPsec Authentication |
SHA-1, SHA-256 |
Encryption |
MPPE, DES, 3DES, AES |
VPN Trunk (Redundancy) |
Load Balancing, Failover |
Single-Armed VPN |
|
NAT-Traversal (NAT-T) |
|
DrayTek VPN Matcher |
|
Firewall & Content Filtering
|
NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
VPN Pass-Through |
PPTP, L2TP, IPsec |
IP-based Firewall Policy |
|
Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense |
|
Spoofing Defense |
|
Bandwidth Management
|
IP-based Bandwidth Limit |
|
IP-based Session Limit |
|
QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
VoIP Prioritization |
|
Wireless LAN (ac/ax model)
|
WiFi 6 |
(ax model) |
Number of SSID |
4 per radio band |
Security Mode |
OWE, WEP, WPA, WPA2, Mixed(WPA+WPA2), WPA3 |
Authentication |
Pre-Shared Key, 802.1X |
OFDMA |
(ax model) |
WPS |
PIN, PBC |
WDS |
Repeater (5GHz only) |
Access Control |
Access List, Client Isolation, Hide SSID, WLAN Scheduling |
AirTime Fairness |
|
Band Steering |
|
MU-MIMO |
(5GHz Only) |
WMM |
|
VoIP Gateway (V model)
|
Protocol |
SIP, RTP/RTCP, ZRTP |
SIP Registrars |
12 |
Dial Plan |
Phone Book, Digit Map, Call Barring, Regional |
Call Features |
Call Waiting, Call Transfer, Scheduled DND, Hotline |
Voice Codec |
G.711 A/u law, G.723.1, G.726, G.729 A/B |
Caller ID |
FSK_ETSI, FSK_BELLCORE, DTMF |
Management
|
Local Service |
HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
Config File Export & Import |
|
Config File Compatibility |
Vigor2926 |
Firmware Upgrade |
TFTP, HTTP, TR-069 |
2-Level Administration Privilege |
|
Access Control |
Access List, Brute Force Protection |
Notification Alert |
SMS, E-mail |
SNMP |
v1, v2c, v3 |
Syslog |
|
Managed by VigorACS |
|
Central VPN Management |
8 VPN |
Central AP Management |
20 VigorAP |
Mesh Network |
7 VigorAP (ac model) |
Central Switch Management |
10 VigorSwitch |
Physical
|
Power Supply |
DC 12V @ 2A |
Max. Power Consumption |
24 watts (ac model) |
Dimension |
241mm x 165mm x 44mm |
Weight |
630g (ac model) |
Operating Temperature |
0 to 45°C |
Storage Temperature |
-25 to 70°C |
Operating Humidity (non-condensing) |
10 to 90% |
Certificate |
|
