Interface
|
WAN/LAN Switchable Port |
1x 2.5G Ethernet, RJ-45 (PoE capable port for P model) 1x GbE/SFP Combo 2x GbE, RJ-45 (PoE capable port(P4) for P model)
*up to 2 simultaneous WANs
|
Fixed LAN Port |
2x GbE, RJ-45 (PoE capable ports for P model) |
USB Port |
1x USB 2.0 + 1x USB 3.0 for storage (since f/w v3.9.6) and USB Thermometer (since f/w v4.3.1) |
Performance
|
NAT Throughput w/ Hardware Acceleration |
2.2 Gbps |
IPsec VPN Performance |
1 Gbps (AES 256 bits) |
SSL VPN Performance |
800 Mbps |
NAT Sessions |
300,000(since f/w v3.9.6, 150,000 with f/w v3.9.3.1 or before) |
Max. Concurrent VPN Tunnels |
200 |
Max. Concurrent OpenVPN + SSL VPN |
50 |
PoE (P model)
|
PoE Capable Ports |
4 (P1/P4/P5/P6) |
PoE Standards |
PoE/PoE+ (802.3af/802.3at) |
Power Budget |
65 watts |
PD Device Check |
|
Internet Connection
|
IPv4 |
PPPoE, DHCP, Static IP |
IPv6 |
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
802.1p/q Multi-VLAN Tagging |
|
Multi-VLAN/PVC |
|
Load Balancing |
IP-based, Session-based |
WAN Active on Demand |
Link Failure, Traffic Threshold |
Connection Detection |
ARP, Ping, Strict ARP |
WAN Data Budget |
(since f/w v3.9.6) |
Dynamic DNS |
|
DrayDDNS |
|
LAN Management
|
VLAN |
802.1q Tag-based, Port-based |
Max. Number of VLAN |
20 |
Number of LAN Subnet |
20 |
DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
LAN IP Alias |
|
Wired 802.1x Authentication |
|
Port Mirroring |
|
Local DNS Server |
|
Conditional DNS Forwarding |
|
Hotspot Web Portal |
|
Hotspot Authentication |
Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server |
Networking
|
Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2, OSPF, BGP |
Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
High Availability |
|
DNS Security (DNSSEC) |
|
IGMP |
IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
Local RADIUS server |
|
VPN
|
LAN-to-LAN |
|
Teleworker-to-LAN |
|
Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN(Host to LAN), Wireguard |
User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
IKE Authentication |
Pre-Shared Key, X.509 |
IPsec Authentication |
SHA-1, SHA-256, MD5 |
Encryption |
MPPE, DES, 3DES, AES |
VPN Trunk (Redundancy) |
Load Balancing, Failover |
Single-Armed VPN |
|
NAT-Traversal (NAT-T) |
|
DrayTek VPN Matcher |
|
Firewall & Content Filtering
|
NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host |
ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
VPN Pass-Through |
PPTP, L2TP, IPsec |
IP-based Firewall Policy |
|
Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense |
|
Spoofing Defense |
|
Bandwidth Management
|
IP-based Bandwidth Limit |
|
IP-based Session Limit |
|
QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Service Type |
VoIP Prioritization |
|
Management
|
Local Service |
HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
Config File Export & Import |
|
Firmware Upgrade |
TFTP, HTTP, TR-069 |
2-Level Administration Privilege |
|
Access Control |
Access List, Brute Force Protection |
Notification Alert |
SMS, E-mail |
SNMP |
v1, v2c, v3 |
Syslog |
|
Managed by VigorACS |
|
Central AP Management |
50 VigorAP |
Central Switch Management |
30 VigorSwitch |
Physical
|
Rack Mountable |
Mouting Kit Included |
Power Supply |
AC 100-240V @ 1A |
Max. Power Consumption |
100 watts (P model) |
Dimension |
273 mm x 171 mm x 45 mm |
Weight |
1.53 kg (P model) |
Operating Temperature |
0 to 45°C |
Storage Temperature |
-25 to 70°C |
Operating Humidity (non-condensing) |
10 to 90% |
Certificate |
|
